Joining
|
wafer |
|---|---|
|
Nominal diameter DN
|
125 mm |
|
Mounting length
|
180 mm |
| Diameter of the passage d | 108 mm |
|
Nominal pressure PN
|
16 bar |
| Type of passage | standard pass (narrower) |
|
Valve body
|
cast |
| Body Material | stainless steel |
| Body material grade | AISI 304 (08Х18Н10) |
| Sealing ball | PTFE |
| Maximum temperature of the working medium | 180°С |
| Working environment | water, hot water, steam, gas, air, neutral environment, weakly aggressive environment, edible fluid |
|
Type of crane
|
two-way |
| Crane feature | with lever, with a platform under the drive, shortened body |
|
Control
|
manual |
| Number of holes for fasteners | 8 |
| Diameter of bolts or studs | М16 |
| Manufacturer | ARMAVAL |
|
Country of manufacturer
|
China |
